VL SPEEDOMETER WITH LCD 85MM This multifunctional gauge with segment display is intended for use in the marine market in […]

VL SPEEDOMETER WITH LCD 85MM

This multifunctional gauge with segment display is intended for use in the marine market in open boats. Based on the ViewLine housing concept, the cluster provides an ideal IP protection class, a modern appearance and high quality standards. It provides many parameters in NMEA 2000® and there are several customization opportunities to meet specific customer demands

Embedded GPS antenna

Range available 0-12 / 0-35 / 0-70 knots ( black dial and bezel only ) 8,5 – 16 Volt

  • • Robust and flexible design for versatile applications
  • • CAN capability (NMEA 2000®)
  • • Pointer for analog indication of Speed over Ground (SOG)
  • • Programmable speed alarm
  • • Fixed segment LCD display
  • • Flush mount possibility
  • • Front side protection rating IP67
  • • Compass for Course over Ground (COG)
  • • Clock

PACKAGE CONTENTS

GPS speed gauge, GPS speed cable, round bezel, pushbuttons for mode and configuration, spinlock nut, rubber seal, QR code, safety instructions

Label Value
Outer diameter 126 mm
Installation diameter 110 mm
Installation depth 50 mm
Front side protection rating IP67

VDO SKU

SKU

RANGE
(knots/kmh/mph)

VOLTAGE

OPERATING TEMPERATURE

A2C59501987

60226IA

0 - 12

8.5 - 16 V

-20° / +85°C

A2C59501782

60227JA

0 - 35

8.5 - 16 V

-20° / +85°C

A2C59501781

60228MA

0 - 70

8.5 - 16 V

-20° / +85°C
