Marinco is the leading supplier of horns to the marine industry, with over a fifty years of experience in designing and manufacturing sound devices specifically for use in harsh marine environments. Stainless steel is used for all critical components such as trumpets, motor cover, diaphragms and mounting hardware. Marinco offers a complete line of marine horn products designed to meet almost any need, including electric and air trumpet horns, compact horns, below deck and deck horns
DROP-IN BELOW DECK HORNS – ELECTRIC COMPACT HORNS
11080 – Drop-in Hidden Horn without Grill
11187 – Screw-in White ASA Grill for 11080
11188 – Screw-in Black ABS Grill for 11080
11096 – Screw-in Stainless Steel Grill Kit for 11080: includes stainless steel grill cover and plastic white (11187) screw-in grill
- • Easy installation: 69,8mm (2.75”) diameter hole x 25,4mm (1”) deep
- • 12 Volt, maximum Amp draw: 4 Amp
- • dB(A) rating: 111 at one meter
- • Fundamental frequency: 370±20Hz
- • Grills have water resistant fabric liners. Ordered separately.
- • Easy retrofit
DROP-IN “H” HORN WITH GRILLS
10079 – Drop-in “H” Horn with Grills
- • Comes with both black ABS and white ASA snap-in grills
- • dB(A) rating: 107 at one meter
- • Fundamental frequency: 370±20Hz
- • Internal space requirements: H 50,8mm (2”) x W 85,6mm (3.37”) x D 82,5mm (3.25”)
- • Distinctive marine horn sound
- • Easy installation or retofit, mounts from the outside
- • 12 Volt, maximum Amp draw: 4 Amp
DROP-IN HIDDEN HORN WITHOUT GRILL
11095 – Drop-in Hidden Horn without Grill
11090 – Snap-in White ASA Grill for 11095
11091 – Snap-in Black ABS Grill for 11095
11225 – Snap-in Chome Plated ABS Grill for 11095 horn
- • Internal space requirements: H 57,2mm (2.25”) x W 92,2mm (3.63”) x D 88,9mm (3.5”)
- • Maximum Amp draw: 3 Amp
- • dB(A) rating: 105 at one meter
- • Fundamental frequency: 440±20Hz
- • Mounts from the outside, horn grill snap on for easy installation
- • Easy retrofit
- • Grill must be ordered separately
Label | Value |
---|---|
DROP-IN BELOW DECK HORNS | 69,8mm (2.75”) diameter hole x 25,4mm (1”) deep |
DROP-IN “H” HORN WITH GRILLS | Internal space requirements: H 50,8mm (2”) x W 85,6mm (3.37”) x D 82,5mm (3.25”) |
DROP-IN HIDDEN HORN WITHOUT GRILL | Internal space requirements: H 57,2mm (2.25”) x W 92,2mm (3.63”) x D 88,9mm (3.5”) |
Model | Part Number | Description |
---|---|---|
DROP-IN BELOW DECK HORNS | ||
66904V | 11080 | Drop-in Hidden Horn without Grill |
66905X | 11187 | Screw-in White ASA Grill for 11080 |
66906Z | 11188 | Screw-in Black ABS Grill for 11080 |
66907B | 11096 | Screw-in Stainless Steel Grill Kit for 11080: includes stainless steel grill cover and plastic white (11187) screw-in grill |
DROP-IN “H” HORN WITH GRILLS | ||
66908D | 10079 | Drop-in “H” Horn with Grills |
DROP-IN HIDDEN HORN WITHOUT GRILL | ||
66909F | 11095 | Drop-in Hidden Horn without Grill |
66910P | 11090 | Snap-in White ASA Grill for 11095 |
66911S | 11091 | Snap-in Black ABS Grill for 11095 |
66912U | 11225 | Snap-in Chome Plated ABS Grill for 11095 horn |
