Il BatteryProtect Smart scollega la batteria dai carichi non fondamentali prima della scarica completa (che la danneggerebbe) o prima di raggiungere un livello di carica insufficiente per l’avviamento del motore.
Utilizzando il Bluetooth per programmare il BatteryProtect Smart, si può impostare qualsiasi livello necessario di attivazione/disattivazione. In alternativa, si può impostare con il pin di programmazione uno dei nove livelli di attivazione/disattivazione predefiniti (vedere manuale).
Se necessario, si può disattivare il Bluetooth.
No data found.
Specifiche tecniche
Model |
Part No. |
Max continuous current |
Peak current |
Operating voltage range |
Load disconnect delay |
Dimensions HxWxD mm (") |
Weight kg (lbs) |
---|---|---|---|---|---|---|---|
BP-65 |
69853W |
12/24V 65A |
250A |
6-35V |
1 minute |
40x48x106 (1.6x1.9x4.2) |
0,2 (0.5) |
BP-65 Smart |
22835E |
12/24V 65A |
250A |
6-35V |
1 minute |
40x48x106 (1.6x1.9x4.2) |
0,2 (0.5) |
BP-100 |
69854Y |
12/24V 100A |
600A |
6-35V |
1 minute |
59x42x115 (2.4x1.7x4.6) |
0,6 (1.3) |
BP-100 Smart |
22836G |
12/24V 100A |
600A |
6-35V |
1 minute |
59x42x115 (2.4x1.7x4.6) |
0,6 (1.3) |
BP-220 |
69855A |
12/24V 220A |
600A |
6-35V |
1 minute |
62x123x120 (2.5x4.9x4.8) |
0,8 (1.8) |
BP-220 Smart |
22837J |
12/24V 220A |
600A |
6-35V |
1 minute |
62x123x120 (2.5x4.9x4.8) |
0,8 (1.8) |
Specifiche tecniche
Model | Part Number | Description |
---|---|---|
BP-65 | 69853W | Protezione batterie |
BP-65 Smart | 22835E | Protezione batterie Smart |
BP-100 | 69854Y | Protezione batterie |
BP-100 Smart | 22836G | Protezione batterie Smart |
BP-220 | 69855A | Protezione batterie |
BP-220 Smart | 22837J | Protezione batterie Smart |
